Ethernet Cable Testers
（以太網絡測試儀）
 |
|
|
|
|
250220
Coaxial BNC/TNC Cable Tester
250220 同軸線纜測試器
This basic
Ethernet cable tester is one of the most affordable
coaxial cable testers in the market. Use it to
quickly root out shorts, open wires or other
continuity problems in BNC and TNC-terminated
coaxial cables. Installed cables can be tested with
the included remote terminator.
 |
|
|
|
|
|
250451
Multi-Modular Cable Tester
250451 多功能電話測試器
The
Multi-Modular Cable Tester is specifically designed
to test modular-terminated (RJ45, RJ11, RJ12) for
wire continuity and miswiring. It can be used to
test a variety of pin configurations such as USOC 4,
USOC 6 and USOC 8, no matter whether the pins are
crossed or wired straight through. Moreover, with
the remote terminator, you may perform all of the
above tests on installed cables.
|
|
|
|
|
|
251452
Enhanced Network
Cable Tester
251452 加強型網路測試器
This tester
quickly identifies continuity problems such as
shorts, open wires, reversed pairs, crossed pairs
and miswiring for 10BASE-T, 100BASE-T, EIA/TIA
568A/568B and Token Ring cables. Moreover, this
tester will verify shield integrity for all STP
cables. Use the included remote terminator to test
installed cables.
|
|
|
|
|
|
251450/E
Network Cable Tester-E
251450/E 簡易多功能網絡線測試器
The Network
Cable Tester-E is our most affordable tester and now
features the ultra convenient design with a compact
remote terminator that slides into the master unit
casing. Use it to quickly test network cables such
as TIA568A/568B, Token Ring and 10/100Base-T cables
for continuity, shorts and open wires.
|
|
|
|
|
|
251451/E
Multi-Network Cable Tester-E
251451/E 多功能網路測試器
The Multi
Network Cable Tester-E is specifically designed for
quick testing of your network cables. Featuring high
speed auto scanning for wire continuity, miswiring
and shield integrity. Use this compact tester to
test TIA568A/568B, Token Ring and 10/100Base-T (UTP/STP)
cables. Test installed cables with the compact
remote terminator that conveniently "piggy-backs"
onto the master unit to prevent misplacement.
|
|
|
|
|
中文說明 |
256451
NETest
Remote Network
Cable Tester
NETest 遙控網路線測試器
The NETest?nbsp;network
cable tester is a simple but comprehensive cable
tester that will diagnose wiring faults for 10BASE2
(Coax), 10BASE-T, 100BASE-Tx, EIA/TIA-586A, EIA/TIA-568B
and Token Ring cables. It will not only identify
wiring faults such as open wires, shorts, reversed
pairs, crossed pairs, SPLIT pairs and miswiring, but
also will identify up to 4 different cables from the
tested end.
|
|
|
|
|
中文說明 |
256551
LANtest
線纜測試類
The LANtest is
the simplest and most affordable wire-mapping device
for networking cables available on the market. Use
it to read the actual wiring configuration for Cat5;
coaxial and modular telephone cables by comparing
one transmitting end to another receiving end.
Cabling faults such as open wires, shorts, miswiring
and crossed pairs are crystal clear with the LANtest抯
unique LED display. Perform all the above tests on
installed cables with the included remote
terminator.
|
|
|
|
|
中文說明 |
256652/LBT
LANtest
Pro with tone generator
256652/LANtest
Pro
遙控網路線測試器組
The
LANtest Pro is a small hand-held tester that enables
the user to quickly read the status of Ethernet
twisted pair cables. It tests for faults such as
open circuits, shorts, crossed pairs, reversed pairs
and SPLIT pairs in seconds. The built-in tone
generator is capable of emitting a continuous or
warble tone. Use the LANtest Pro in conjunction with
any cable tracer in the market to trace cables and
locate faults. You'll never lose your remote
terminator again with this patented 2-in-1 design.
|
|
|
|
|
中文說明 |
256652/TK
LANtest Pro and Probe Kit
LANtest Pro 遙控網路線測試器組
This is
truly the most affordable all in one solution to
cable continuity testing, fault locating and cable
tracing. The LANtest Pro can be used to root out all
continuity and polarity faults on Ethernet twisted
pair cables. The included Probe is the perfect
companion to the LANtest Pro's toner function,
allowing the user to trace cables through walls and
locate faults.
|
|
|
|
|
|
